Powerwalker VFI-2000AT(PS), 2000VA/1800W, Online UPS, 4x Schuko (10122181)
Κωδικός Cableworks: 1197.057

BrandPOWERWALKER MPNVFI2000AT(PS)

€517.45

χωρίς ΦΠΑ €417.30

Σε Απόθεμα

Ποσότητα:

+ −

Αποστολές & Επιστροφές

Τρόποι πληρωμής

Γιατί Cableworks;

Datasheet

Κατεβάστε το - 318 Kb

Γρήγορη και ασφαλής παράδοση

Αποστέλλουμε παραγγελίες σε όλη την Ελλάδα με ΕΛΤΑ Courier και ACS

Presales και Aftersales

Για να σας λύνονται όλες οι τεχνικές απορίες

Επιστροφές εντός 14 ημερών

Αρκεί το προϊόν να μην έχει ανοιχτεί και να μην έχουν προκληθεί φθορές στην συσκευασία του

CABLEWORKS

Αναλυτική Παρουσίαση

Model: VFI 2000 AT
SKU: 10122181

USB with Human Interface Device (HID) support
It includes an Intelligent Slot for communication cards
Wide Input Voltage Range for All Environments
It supports AC Generators
Several Outlet Versions – Type F, Type E and Type G
Easy to connect Battery Packs
Auto-Dimming LCD (UPS is woken up with Single Button-Click)
It offers EPO (Emergency Power Off) and ROO (Remote On / Off) function

The PowerWalker VFI AT is an Online UPS series with double conversion technology, designed to safeguard your mission-critical equipment. Despite its professional application, the VFI AT series is easy to operate and comes inside a compact and economic package.

Rather uniquely among Online UPS, the VFI AT series features outlet sockets for Type F, Type E and Type G plugs. This broadens its usability and allows for different types of application. Multiple optional accessories such as external battery packs and communication cards, enhance the functionality of the UPS and allow for a greater backup time.

General Features
Type	Online Single Phase (VFI)
Phases (IN-OUT)	1-1
Form Factor	Tower
Power Capacity	2000VA / 1800W
Output Power Factor	0.90
Input
Input Voltage Range	80-300V @ 0-50% load 120-300V @ 50-60% load 140-300V @ 60-80% load 160-300V @ 80-100% load
Frequency Range	40Hz – 70Hz
Frequency (Synchronized Range)	Adjustable 1-10% (default ±8%) Outside of the range, it switches to converter mode
DC Input (PV)
Input Power Factor	≥ 0.99 at full load
Output
Waveform	Pure Sine Wave
VA	2000
Load Crest Ratio	3:1
Nominal Output Voltage	208/220/230/240 VAC
THDv	≤3% @ 100% linear load, ≤5% @ 100% non-linear load
Frequency (Battery Mode)	±0.5Hz
Output Power Factor	0.90
Input & Output Connectors
Input Connector	C14
Type F (CEE 7/3)	4
Technical Details
LINE Mode Efficiency [%] (Full Load)	90.0
ECO Mode Efficiency [%] (Full Load)	95.0
Transfer Time (AC / Line Mode or Battery Mode to ECO Mode) [ms]	10ms
Transfer Time (AC / Line Mode to Battery Mode) [ms]	0ms
Transfer Time (ECO Mode to AC / Line Mode or Battery Mode) [ms]	10ms
Transfer Time (Line Mode or Battery Mode to Bypass Mode) [ms]	4ms
Load Crest Ratio	3:1
Additional Features	ECO Mode Available, CVCF Mode Available, REPO – Remote Emergent Power-Off, APFC – High Input PF, LCD Display, Battery Pack Available, Circuit Breaker Reset, Generator Compatible, HID – Human Interface Device, AVR – Automatic Voltage Regulator
IEC 62040-3 classification	VFI-SS-111
Batteries and Autonomy
Batteries	4x 12.0V/9.0Ah
DC Voltage	4x 12.0V
Recharge Time	4h to 90%
Full Load Backup Time [min]	4.0
Half Load Backup Time [min]	11.0
Charger	1.5A
External Battery Pack	GPS40AFP-G3011G3
Recharge Time	4h to 90%
Communication
Communication	USB Type B – for Monitoring Software, RS-232, Management Card Slot
Software	PowerMaster
Management and Environment
Software	PowerMaster
Communication	USB Type B – for Monitoring Software, RS-232, Management Card Slot
Noise Level	< 45dB
Fan Logic	Always on, Automatic Speed Control
Temperature	0°C – 40°C
Humidity	20% – 90% RH (non-condensing)
IP	IP 20
