Ubiquiti UniFi Dream Machine Special Edition (UDM-SE), USG + UniFi Controller + Unifi PoE Switch + Unifi Protect + Dual Wan (1x 2.5Gbe & 1xSFP+), 8xPoE Gigabit (6x802.3af + 2x802.3at), 1xSFP+, Quad-Core 1.7GHz, 4GB, 16GB eMMC, 1xBluetooth, 1x 3.5'' HDD So
Κωδικός Cableworks: 1001.462

BrandUbiquiti MPNUDM-SE ΕΓΓΥΗΣΗ24 μήνες

€660.00

χωρίς ΦΠΑ €532.26

Μη Διαθέσιμο

Ειδοποίηση όταν το προϊόν είναι ξανά διαθέσιμο

Αποστολές & Επιστροφές

Τρόποι πληρωμής

Γιατί Cableworks;

Datasheet

Κατεβάστε το - 4,864 Kb

Γρήγορη και ασφαλής παράδοση

Αποστέλλουμε παραγγελίες σε όλη την Ελλάδα με ΕΛΤΑ Courier και ACS

Presales και Aftersales

Για να σας λύνονται όλες οι τεχνικές απορίες

Επιστροφές εντός 14 ημερών

Αρκεί το προϊόν να μην έχει ανοιχτεί και να μην έχουν προκληθεί φθορές στην συσκευασία του

CABLEWORKS

Αναλυτική Παρουσίαση

All-in-one router and security gateway with an integrated PoE switch and network video recorder.

The Dream Machine Special Edition (UDM SE) is an enterprise-grade UniFi OS Console capable of helping home and business owners alike seamlessly scale and manage their networks with high-speed, dual-WAN connectivity (10G SFP+ and 2.5GbE RJ45 ports), a Gigabit, PoE switch, and a network video recorder (NVR) with 128 GB of internal storage. Powered by UniFi OS, the UDM SE gives you full control of all your UniFi devices, including access points, Protect cameras, Talk phones, and Access readers. It's also a future-proof console since it will be able to run all upcoming UniFi OS applications. Engineered for end-to-end simplicity, the UDM SE features an integrated Bluetooth radio that streamlines the initial setup and configuration process, which can be completed in minutes with the UniFI Network application (web or mobile).

Features:

1.7 GHz quad-core processor
Dual WAN ports (10G SFP+ and 2.5GbE RJ45)
(8) GbE RJ45 ports, including (6) 802.3af PoE and (2) 802.3at PoE+ LAN ports
(1) 10G SFP+ LAN port
(1) 1.3" LCM color touchscreen for at-a-glance network monitoring
Customizable internet threat filtration and traffic identification for enhanced network security
Quick, Bluetooth-powered setup via the UniFi Network web application or mobile app
1U-sized, rack-mountable device
Connect a SmartPower Redundant Power System to create an uninterruptible network
Integrated security gateway and UniFi Protect-ready NVR that supports compatible 3.5" HDDs
128 GB integrated storage for full UniFi OS Application experience

Note: The included UK power lead is a standard lead without a security clip. A UK-specific version of this product is coming soon.

Mechanical
Dimensions	442.4 x 43.7 x 285.6 mm (17.42 x 1.72 x 11.24")
Weight	4.95 kg (10.91 lb)
Enclosure materials	Aluminium CNC, SGCC steel
Mount material	SGCC steel rack mount
Hardware
Processor	Quad-Core ARM^® Cortex^®-A57 at 1.7 GHz
System memory	4 GB DDR4
On-board storage	16 GB eMMC Integrated 128 GB SSD
IDS/IPS throughput	3.5 Gbps* _{*Measured with iPerf3}
Max. power consumption (excluding PoE output)	50W
Power method	(1) Universal AC input, 100-240VAC, 4.4A Max, 50/60 Hz (1) USP-RPS DC input, 52VDC, 3.94A
Power supply	AC/DC, Internal, 240W
Supported voltage range	100 to 240VAC
Management interfaces	Ethernet Bluetooth
Networking interfaces	(1) WAN: 2.5 GbE RJ45 port (8) LAN: 1 GbE RJ45 ports
SFP+ interfaces	(1) WAN: 10G SFP+ (1) LAN: 10G SFP+
PoE interfaces	(2) PoE+ IEEE 802.3at (pair A 1, 2+; 3, 6-) (6) PoE IEEE 802.3af (pair A 1, 2+; 3, 6-)
Max. PoE wattage per port by PSE 802.3af	15.4W
Max. PoE wattage per port by PSE 802.3at	30W
Voltage range 802.3af mode	44 to 57V
Voltage range 802.3at mode	50 to 57V
ESD/EMP protection	Air: ± 15 kV, contact: ± 8 kV
LCM display	(1) 1.3" touchscreen Bootup animation: bootup in progress Firmware upgrade icon: firmware upgrading
Button	Factory reset
Operating temperature	-10 to 40° C (14 to 104° F)
Operating humidity	5 - 95% noncondensing
Certifications	CE, FCC, IC
LEDs
Ethernet	White: link/activity
SFP+	White: link/activity
HDD	White: disk activity Amber: disk error
RPS	Blue: ready
