Ubiquiti UISP Wave-AP, 60 GHz PtMP access point powered by Wave Technology, 5GHz Backup Radio, up to 2.7 Gbps duplex (Supported Stations Wave-Nano & Wave-LR)
Κωδικός Cableworks: 1001.536

BrandUbiquiti MPN UISP Wave-AP ΕΓΓΥΗΣΗ24 μήνες

€684.90

χωρίς ΦΠΑ €552.34

Σε Απόθεμα

Ποσότητα:

+ −

Αποστολές & Επιστροφές

Τρόποι πληρωμής

Γιατί Cableworks;

Datasheet

Κατεβάστε το - 753 Kb

Γρήγορη και ασφαλής παράδοση

Αποστέλλουμε παραγγελίες σε όλη την Ελλάδα με ΕΛΤΑ Courier και ACS

Presales και Aftersales

Για να σας λύνονται όλες οι τεχνικές απορίες

Επιστροφές εντός 14 ημερών

Αρκεί το προϊόν να μην έχει ανοιχτεί και να μην έχουν προκληθεί φθορές στην συσκευασία του

CABLEWORKS

Αναλυτική Παρουσίαση

60 GHz PtMP access point powered by Wave Technology.

The Wave Access Point can connect up to 15 stations and deliver up to 5.4 Gbps total throughput (2.7 Gbps duplex). It is equipped with a high-performance 5 GHz backup radio to ensure uninterrupted connection, as well as a Bluetooth radio to simplify setup in the UISP® Mobile app.

Features:

5 GHz backup radio
Supported stations and distances:
– Wave Long-Range: up to 8 km
– Wave Nano: up to 5 km
WAN Ports: (1) 10G SFP+, (1) 2.5GbE
Integrated GPS antenna
Link planning support via the ISP Design Center

Mechanical
Dimensions	212 x 205 x 187 mm (8.3 x 8.1 x 7.4")
Weight	2.3 kg (5.07 lb)
Enclosure materials	Aluminum alloy, UV stabilized polycarbonate
Pole mount diameter	25 to 76 mm (1 to 3") on pipe outer diameter
Wind loading	98 N at 200 km/h (22 lbf at 125 mph)
Weatherproofing	IPX6
Hardware
Processor	Quad ARM® Cortex®-A53 cores at 1.4 GHz
Memory	DDR3L 512 MB
Networking interface	(1) 2.5GbE RJ45 port (100/1000/2500)* (1) 10G SFP+ port (1/10) * Active only when SFP+ port is down.
Max. power consumption	24W
Power method	48V DC passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-) or 2-pairs (4, 5+; 7, 8-) 24V DC passive PoE 4-pairs (1, 2+; 3, 6-) (4, 5+; 7, 8-)
Power supply	48V DC, 0.65A 2.5GbE PoE adapter (included)
GPS	Yes
Button	Factory reset
LEDs	Power, Ethernet, GPS
Operating temperature	-40 to 60° C (-40 to 140° F)
Operating humidity	5 to 95% noncondensing
Certifications	FCC, IC, CE
Software
OS	airOS®
Operating mode	PtMP access point
Ubiquiti specific features	Wave AI, discovery protocol
Services	UISP, ping watchdog, NTP client, SNMP
Tools	Antenna alignment, discovery utility, ping, trace route, speed test
Network	Bridge mode
Software management	Bluetooth management for easy setup over UISP Mobile app WEB UI
Minimum software requirements	Any modern web browser/iOS™ or Android™ based smartphone
System
Total throughput	5.4 Gbps (2.7 Gbps duplex)
Supported clients count	15
Range	Connecting to a Wave Long-Range: up to 8 km Connecting to a Wave Nano: up to 5 km
Encryption	WPA2-PSK (AES)
RF
Operating frequency*	57 to 71 GHz *Depends on regulatory region.
Channel bandwidth	2160, 1080 MHz
Operating channels*	58320, 59400, 60480, 61560, 62640, 63720, 64800, 65880, 66960, 68040, 69120, 70200 MHz *Depends on regulatory region.
Modulation	16QAM, QPSK
Antenna gain	24 dBi
Polarization	Vertically linear
Beamwidth	Azimuth: 30° Elevation: 3 dB 3°, 6 dB 4°
Electrical downtilt	0°
Back-Up RF
WiFi standard	802.11ax (WiFi 6)
Operating frequency* US/CA Worldwide	U-NII-1 5150 - 5250 MHz U-NII-2A 5250 - 5350 MHz U-NII-2C 5470 - 5725 MHz U-NII-3 5725 - 5850 MHz 5150 - 5875 MHz *Depends on regulatory region.
Channel bandwidth	20, 40, 80 MHz
Modulation	BPSK (1⁄2), QPSK (1⁄2), QPSK (3⁄4), 16QAM (1⁄2), 16QAM (3⁄4), 64QAM (2⁄3), 64QAM (3⁄4), 64QAM (5⁄6), 256QAM (3⁄4), 256QAM (5⁄6), 1024QAM (3⁄4), 1024QAM (5⁄6)
Antenna gain	12 dBi
Cross-pol isolation	10 dB
Electric downtilt	0°
LEDs
Power	Flashing white: bootup in progress White: not connected to UISP application Blue: connected to UISP application Flashing blue: locate in progress Blue/white: firmware upgrade in progress
Ethernet	Flashing white: Ethernet traffic detected Flashing blue: SFP+ traffic detected
GPS	Blue: receiving at least (4) GPS satellite signal
