Grandstream GWN7660E AX3000 Wi-Fi 6 Dual-band 2.4G 2x2:2 and 5G 3x3:2 MU-MIMO with XTRA Range Technology Access Point, POE

Κωδικός Cableworks: 1015.108

Grandstream GWN7660E is an enterprise-grade Wi-Fi 6 access point that allows businesses to build next-generation Wi-Fi networks for high-density environments. Offers 2x2:2 MU-MIMO technology on the 2.4G band and 3x3:2 MU-MIMO on the 5G band. With a sophisticated antenna design and XTRA Range technology with beamforming, delivers maximum network throughput and expanded Wi-Fi coverage range. To ensure easy installation and management, the GWN7660E uses a controller-less distributed network management design, in which the controller is embedded within the product’s Web user interface, and is also supported by GWN.Cloud and GWN Manager, Grandstream’s cloud and on-premise Wi-Fi management platform. It is the ideal Wi-Fi AP for voice-over-Wi-Fi deployments and offers a seamless connection with Grandstream’s Wi-Fi capable IP phones. With support for advanced QoS, low-latency real- time applications, mesh networks, captive portals, 256 concurrent clients per AP and Gigabit network ports with PoE/PoE+, GWN7660E is an ideal Wi-Fi access point for medium wireless network deployments with medium-to-high user density.

Key Features & Benefits:

• Dual-band 2.4G 2x2:2 and 5G 3x3:2 MU- MIMO with XTRA Range technology
• 3Gbps aggregate wirelessthroughput and 1Gigabit wireline port
• Up to 175-meter coverage range
• Supports 256 concurrent Wi-Fi client devices
• Self power adaptation upon auto detection of PoE or PoE+
• Advanced QoS to ensure real-time performance of low-latency applications
• Anti-hacking secure boot and critical data
• Control lockdown via digital signatures, unique security certificate
• Random default password per device
• Embedded controller can manage up to 50 local GWN series APs
• GWN.Cloud offers unlimited AP management
• GWN Manager offers premise-based software controller
• 3 Year Warranty

Specifications:

• Wi-Fi Standards: IEEE 802.11 a/b/g/n/ac/ax
• Antennas:
  - 5 individual internal antennas
  - 2.4GHz x 2, gain 4.0dBi
  - 5 GHz x 3, gain 5.0dBi
• Wi-Fi Data Rates:
  - 5G:
  - IEEE 802.11ax: 7.3 Mbps to 2402 Mbps;
  - IEEE 802.11ac: 6.5 Mbps to 867 Mbps;
  - IEEE 802.11n: 6.5Mbps to 300Mbps;
  - IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
  - 2.4G:
  - IEEE 802.11ax: 7.3 Mbps to 573.5 Mbps;
  - IEEE 802.11n: 6.5Mbps to 300Mbps;
  - IEEE 802.11b: 1, 2, 5.5, 11 Mbps;
  - IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
• Frequency Bands:
  - 2.4GHz radio: 2400-2483.5MHz
  - 5GHz radio: 5150-5850MHz
• Channel Bandwidth:
  - 2.4G: 20 and 40 MHz
  - 5G: 20,40,80 and 160MHz
• Wi-Fi and System Security:
  - WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES)
  - WPA3, anti-hacking secure boot and critical data
  - Control lockdown via digital signatures, unique security certificate
  - Random default password per device
• MIMO:
  - 2x2:2 2.4GHz
  - 3x3:2 5GHz
• Coverage Range: Up to 175 meters
• Maximum TX Power:
  - 5G: 24dBm
  - 2.4G: 24dBm
• Receiver Sensitivity:
  - 2.4G:
  - 802.11b: -96dBm@1Mbps, -88dBm@11Mbps; 802.11g: -93dBm @6Mbps, -75dBm@54Mbps;
  - 802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz: -70dBm @MCS7;
  - 802.11ax 20MHz: -60dBm @MCS11; 802.11ax 40MHz: -58dBm @MCS11
  - 5G:
  - 802.11a: -92dBm @6Mbps, -74dBm @54Mbps;
  - 802.11n 20MHz: -73dBm @MCS7; 802.11n 40MHz: -70dBm @MCS7;
  - 802.11ac 20MHz: -67dBm@MCS8; 802.11ac: 40MHz: -63dBm @MCS9; 802.11ac 80MHz: -59dBm @MCS9;
  - 802.11ax 20MHz: -60dBm @MCS11; 802.11ax 40MHz: -58dBm @MCS11;802.11ax 80MHz: -56dBm @MCS11;
  - 802.11ax 160MHz: -52dBm@ MCS11
• SSIDs: 32 SSIDs total, 16 per radio (2.4GHz and 5 GHz)
• Concurrent Clients: 256
• Network Interfaces: 1x autosensing 10/100/1000 Base-T Ethernet Port
• Auxiliary Ports: 1x Reset Pinhole, 1x Kensington lock
• Mounting: Indoor wall mount or ceiling mount, kits included
• LEDs: 3 tri-color LEDs for device tracking and status indication
• Network Protocols: IPv4, IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM
• QoS: 802.11e/WMM, VLAN, TOS
• Network Management:
  - Embedded controller can manage up to 50 local GWN APs
  - GWN.Cloud offers a free cloud management platform for unlimited GWN APs
  - GWN Manager offers premise-based software controller for up to 3,000 GWN APs
• Power and Green Energy Efficiency:
  - PoE 802.3af/ 802.3at;
  - Maximum Power Consumption: 12.95W
• Environmental:
  - Operation: 0°C to 50°C
  - Storage: -10°C to 60°C
  - Humidity: 10% to 90% Non-condensing
• Physical:
  - Unit Dimensions: 180.4 x180.4 x40.8mm (TBD)
  - Unit Weight: 385g
  - Entire Package Dimensions: 228.5 x 220 x79mm (TBD)
  - Entire Package Weight: 630g
• Package Content:
  - GWN7660E Wireless AP
  - Mounting Kits
  - Quick Start Guide
• Compliance: FCC, CE, RCM, IC
